Rental & Lease
Equipment

Vertical Form Fill & Seal

From entry-level intermittent systems to high-speed continuous box motion baggers, TDI Packsys carries a Tecno Pack bagging solution for your application. Each system in the FV series features a cantilevered structure for easy cleaning and maintenance, servo-driven sealing, and a 5.7″ touch screen with up to 40 stored product programs. Whether you are running bakery goods, dry fruit, granular products, or fragile items like chips and confectionery, there is a system designed for your line. Read More
Contact Sales
  • This field is for validation purposes and should be left unchanged.

Table of Contents

FV015 / FV016 Series

Tecno Pack FV015 vertical packaging machine with platformTecno Pack FV015 bagging machine with conveyor system

FV015 and FV016 packaging machine dimension drawings

An intermittent style vertical bagger producing pillow and block bottom bags. Suitable for bakery products, dry fruit, candy, granular products, and powder.

FV025 Series

Tecno Pack horizontal flow wrapper with conveyorTecno Pack automatic horizontal packaging machine

Cantilevered VFFS system designed for fragile product filling, such as potato chips or chocolate confectionary products. Angled product descent through the forming tube minimizes fragile product breakage.

Technical Specifications

Drive5 servomotors
FrameEpoxy powder coated steel, RAL 9007 grey
Contact PartsAISI 304 stainless steel
Reel Width520 mm
Longitudinal Seal Bar420 mm, servo assisted
Transversal Seal Jaws270 mm wide, servo driven
ControlIntegrated PLC (OMRON or SIEMENS)
Display5.7″ TFT touch screen
Product DatabaseUp to 40 products

Motorization

  • 400 W — Film pulling belts
  • 1,000 W — Transversal sealing unit
  • 1,500 W — Film unwinding
  • 400 W — Vertical sealing bar movement

Key Features

  • Cantilevered structure for easy cleaning and maintenance
  • Transparent polycarbonate guarding
  • Pneumatically activated expansion blade reel holding
  • Automatic film tension regulation
  • Password-protected user access levels
  • CE compliant safety guards

Control Panel

  • 5.7″ TFT touch screen
  • Product database with up to 40 stored programs
  • Automatic instantaneous product size changeover
  • Service and diagnostic mode
  • Multi-language interface

FV210 Series

Dual Tecno Pack FV210 packaging machines FV210 packaging machine layout and dimensions diagram Tecno Pack FV210 vertical packaging machine Close-up of FV210 packaging and sealing process

Cantilevered intermittent motion VFFS system designed for demanding applications where ease of use, maintenance, and system uptime are paramount. Designed for side-by-side placement of multiple systems for maximum product output.

Technical Specifications

Motion TypeIntermittent
FrameEpoxy powder coated steel, RAL 9007 grey
Contact PartsAISI 304 stainless steel
Reel Width520 mm
Longitudinal Seal Bar420 mm, servo assisted
Transversal Seal Jaws270 mm wide, servo driven
ControlIntegrated PLC (OMRON or SIEMENS)
Display5.7″ TFT touch screen
Product DatabaseUp to 40 products

Motorization

  • 400 W — Film pulling belts
  • 1,000 W — Transversal sealing unit
  • 1,500 W — Film unwinding
  • 400 W — Vertical sealing bar movement

Key Features

  • Cantilevered structure for easy cleaning and maintenance
  • Transparent polycarbonate guarding
  • Automatic film tension regulation
  • Password-protected user access levels
  • CE compliant safety guards
  • Designed for side-by-side multi-unit deployment

Control Panel

  • 5.7″ TFT touch screen
  • Product database with up to 40 stored programs
  • Automatic instantaneous product size changeover
  • Service and diagnostic mode
  • Multi-language interface

FV210LD Series

Automatic vertical packaging machine with film feeder

Cantilevered continuous, high-speed box motion VFFS system designed for demanding applications where product output speed, ease of use, maintenance, and system uptime are paramount. Designed for side-by-side placement of multiple systems for maximum product output.

Technical Specifications

Motion TypeContinuous / Box Motion
FrameEpoxy powder coated steel, RAL 9007 grey
Contact PartsAISI 304 stainless steel
Reel Width520 mm
Longitudinal Seal Bar420 mm, servo assisted
Transversal Seal Jaws270 mm wide, servo driven
ControlIntegrated PLC (OMRON or SIEMENS)
Display5.7″ TFT touch screen
Product DatabaseUp to 40 products

Motorization

  • 400 W — Film pulling belts
  • 1,000 W — Transversal sealing unit
  • 1,500 W — Film unwinding
  • 400 W — Vertical sealing bar movement

Key Features

  • High-speed continuous motion output
  • Cantilevered structure for easy cleaning and maintenance
  • Transparent polycarbonate guarding
  • Automatic film tension regulation
  • Password-protected user access levels
  • CE compliant safety guards
  • Designed for side-by-side multi-unit deployment

Control Panel

  • 5.7″ TFT touch screen
  • Product database with up to 40 stored programs
  • Automatic instantaneous product size changeover
  • Service and diagnostic mode
  • Multi-language interface
